AXOR Citterio MSingle lever basin mixer for concealed installation wall-mounted with spout 227 mm and escutcheons 2 ticks
Finish
Chrome
Art. no. 34123009
Product saved for 30 days.To the product comparison
The article could not be saved.
Please try again.
Please try again.
Required parts
Optional accessories
Spare parts for build year 04/20
| Item no. |
|---|
| c | extension set 25 mm for 1362218031971000 |
| a | base body13622180 |
| d | conversion kit for 3411118095635000 |
| b | pop up waste51301000 |
| e | adapter for exchanged connections93819000 |
| 1 | handle34097000 |
| 2 | screw cover96338000 |
| 3 | flange98863000 |
| 4 | O-Ring 22x298185000 |
| 5 | nut95633000 |
| 6 | cartridge, assy95973000 |
| 7 | locking screw for handle95140000 |
| 8 | seal98865000 |
| 9 | adapter for cartridge95634000 |
| 10 | O-ring 26x298147000 |
| 11 | escutcheon for handle98959000 |
| 12 | washer97600000 |
| 13 | fixing set97971000 |
| 14 | spout 220 mm98935000 |
| 15 | hollow set screw M4x592846000 |
| 16 | aerator M16,5x1 (3,8 l/min)92920000 |
| 17 | special tool98987000 |
| 18 | O-ring 30x1,598433000 |
| 19 | escutcheon for spout98960000 |
| 20 | connecting thread G½98933000 |
| 21 | O-ring 11x298127000 |
| 22 | extension set for 3411118034983000 |
| 23 | nut95178000 |
| 24 | sleeve98535000 |
| 25 | sleeve98958000 |
Innovative technologies
More pleasure, more efficiency
Mixes generous quantities of air into the water. The enriched droplets are luxurious, light and soothing on the skin and cause less splash in the wash basin. For a more efficient use of the precious resource that is water.
Saving resources with pleasure
hansgrohe standard taps are equipped with our EcoSmart technology to save water and energy – since 2010. While enjoying the full water experience, it consumes max. 5 l/min. Good for a conscious consumption of water and energy.
AirPower
More pleasure, more efficiency
Mixes generous quantities of air into the water. The enriched droplets are luxurious, light and soothing on the skin and cause less splash in the wash basin. For a more efficient use of the precious resource that is water.
EcoSmart
Saving resources with pleasure
hansgrohe standard taps are equipped with our EcoSmart technology to save water and energy – since 2010. While enjoying the full water experience, it consumes max. 5 l/min. Good for a conscious consumption of water and energy.
Five-year manufacturer’s guarantee
5
year manufacturer's guarantee
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
