AXOR MontreuxSingle lever basin mixer 100 with lever handle and pop-up waste set 2 ticks
Art. no. 16512009
Please try again.
Spare parts for build year 04/20
| Item no. |
|---|
| a | pop up waste51302000 |
| b | pop up waste94139007 |
| 1 | handle92973000 |
| 2 | cover cap92974000 |
| 3 | O-ring 16x298133000 |
| 4 | screw cover96338000 |
| 5 | pin97766000 |
| 6 | flange92625000 |
| 7 | nut92689000 |
| 8 | O-ring 27x1,592527000 |
| 9 | O-ring 25x1,598146000 |
| 10 | cartridge, assy95973000 |
| 11 | seal98865000 |
| 12 | adapter for cartridge98866000 |
| 13 | O-ring 23x298398000 |
| 14 | O-ring 11x2,598487000 |
| 15 | spout cpl.92978000 |
| 16 | hollow set screw M6x598447000 |
| 17 | aerator M22x1 (3,5 l/min)93784000 |
| 18 | fixing set (Ø 34)95049000 |
| 19 | lever collar97548000 |
| 20 | pull rod98730000 |
| 21 | connection hose 600 mm M8x0,75 G1/292482000 |
| 22 | O-ring 7x1,598422000 |
Innovative technologies
More pleasure, more efficiency
Excellent user comfort
Saving resources with pleasure
AirPower
More pleasure, more efficiency
Mixes generous quantities of air into the water. The enriched droplets are luxurious, light and soothing on the skin and cause less splash in the wash basin. For a more efficient use of the precious resource that is water.
ComfortZone
Excellent user comfort
More elbow room when washing hands, a comfortable way to wash hair or just fill containers: The better the tap fits the space, the more flexible the options become. We call the area between the tap and the ceramics the ComfortZone because you can use it however you like.
EcoSmart
Saving resources with pleasure
hansgrohe standard taps are equipped with our EcoSmart technology to save water and energy – since 2010. While enjoying the full water experience, it consumes max. 5 l/min. Good for a conscious consumption of water and energy.
