AXOR Starck
Single lever shower mixer for exposed installation with round lever handle 2 ticks

product.image.alt
 View in AR
 360° view
Finish Chrome

Art. no. 12612009

Article features

  • consists of: single lever shower mixer
  • 1 function
  • centre distance: 150 ± 16 mm
  • ceramic cartridge
  • temperature limitation adjustable
  • non-return valve
  • with silencer
  • suitable for continous flow water heaters
  • hose connection DN15
  • connection dimension: DN15
  • min. operating pressure: 1 bar
  • max. operating pressure: 10 bar
  • connection type: s-shaped connections
  • WELS SGP 2 Ticks SHT-2019/028688/SLS

Downloads

Technical drawings

Instructions

Download all Instructions files
Download all files

Installation information

Scale drawing

Download all files

Information

Please always observe the safety and installation information for your product. You find these details within the assembly instructions.

Spare parts for build year 04/20

To the spare parts catalog
To the spare parts catalog
product.spareparts.image.alt
Item no. DescriptionArticle no.Description and article no.
1 handle10093000
2 screw cover96762000
3 flange96763000
4 nut97209000
5 O-ring 33x298154000
6 cartridge, assy92730000
7 O-ring 29x298391000
8 O-ring 11x298127000
9 non return valve92839000
10 escutcheon Ø 59 mm97507000
11 noise reduction96429000
12 set of S-unions with nuts96742000

Five-year manufacturer’s guarantee

5

year manufacturer's guarantee

 Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
We endeavour to always provide up-to-date, complete information on our website. However, we do not assume any liability for the suitability of the information for particular uses.
